224-310KW广西顶博发电机组制造:康明斯发电用发动机可靠性高：高强度合金铸造缸体、可锻铸铁(FCD) 活塞，刚性更好，降低振动和噪声，提高了发动机适应更高的爆发压力。

High reliability: intensified alloy casting cylinder and Ferrous Cast Ductile (FCD) piston provide engine a better rigidity performance and lower vibration & noise, and also make the engine adapt to higher explosion pressure.

康明斯带发电用发起机燃料合理性性好: 优秀的燃料管理体系，别具一格 的STC、ESTC 划分管理体系，特种构思的连杆顶面自燃室，高压力压喷射燃料，加以雾化吸入，自燃加以。

Good fuel economy: Advanced fuel control system, unique STC, ESTC step control system, specilly-designed piston topchamber and high pressure fuel injection lead to an excellent fuel consumption rate and emission performance of engine.

康明斯风能发电用热车机瞬态功效表现出色: 无极限的热车机大体制定，互相配合康明斯个性的EFC操作系统，操作高精程度高，异常用时快。

Excellent transient performance: perfect overall engine design with unique Cummins EFC system, high precision on control and quick response time.

康明斯带发电用启行为升耗油率高: 纵向定制紧身.自己的外观安装合理安排，正常运作顺畅。High lift power: Integrated and compact design, reasonable layout and smooth operation.

电喷网络制式 QSNT. QSK19. QSK38. QSK50充分满足中国现代非通道第三点周期及北美洲Tier2. Tier 3尾气排放法律规范需要。

Electric fuel injection engines (QSNT,QSK19,QSK38,QSK50) meet the Tier3 emission regulations for China non-road vehicles and Tier2 & Tier3 emission regulations of North America.

零备品备件能得性好， 打火机正常运行及维修清洁清洁方便快捷，的费用低。Good availbility of spare parts, smooth engine operation, convenient engine maintenance and low cost.

发动机规格Engine Specifications

额定功率範圍 Power Range   224-310KW连接结构 Type   直列/六缸/四冲程/四气门  In-ine/6-Cylinder/4-Stroke/4-Valve缸径x冲程 BoreX Stroke  125X 147mm排量 Displacement   11L自己的外观规格尺寸 Dimension  长X宽X高(LXWX H) 1360 x 833X 1068 mm净效果 Dry Weight   940kg

224-310KW康明斯并网发电用发起机的特性：比热容小， 减小比低， 除雾器空气的热处理加热，不易打火，转动车载式电源开关的选择。Compact size, high compression ratio, gile heated by air, easy for start-up, the first option of mobile vehicle power supply.

推荐机型Engine Models Recommended

打火机产品型号	经常用耗油率(kW)Prime Power	备品热效率kW)Standby Power
MTA11-G2	224	246
MTAA11-G3	282	310
